E-RICKSHAW / E-SCOOTER COMPONENTS

Motors, controllers & mechanical parts built for the road.

We specialize in Electric Vehicles, providing motors, chargers, shock absorbers and controllers for e-rickshaws & e-bikes since 2017. Based in Delhi and Singapore, with our own design & development facilities.

Motors (BLDC) — 48V

BLDC motors up to 3000W with best-quality neodymium magnets.

Power	No-Load Current	No-Load RPM	Max Torque	Weight (kg)
48V 900W	≤4.3	3200	>200Nm	4.5
48V 1000W	≤4	3100	>220Nm	5.15
48V 1100W	≤4.5	3100	>230Nm	5.25
48V 1200W	≤4	3100	>250Nm	6.23

Motor Controller — 48V Square Wave

Made in India with special MOSFETs for high-temperature conditions.

Motor Power	Current (A)	Phase Angle	Under-V Cut	Upper-V Cut
900W	45	120	41V	65V
1000W	50	120	41V	65V
1200W	60	120	41V	65V

Differential

Heavy-duty differentials, capable of navigating the roughest of roads with ease.

Load Capacity	Max Speed	Gear Ratio	Transmission Eff.	Braking Diameter
400–1000kg	Up to 30 km/h	1:10	>90%	160/180

Heavy Duty Shock Absorber

Inner, outer & rebound compression springs made of superior material
Quad ring provided
Additional protection from dust entry
OD ground & hard chrome plated for better wear resistance

Yellow zinc-iron plated
MIG (CO2) welding
Double-seal protection against dust & moisture
Service-free — dust protected

DC-DC Converter

48V to 12V converter with high conversion efficiency.

Charger

SMPS-based, high efficiency, and picks up charge even in cold climates.
